XCMG XCT12L5
Cena bez PDV-a
6
2
Omiljeno
Dio
Sačuvaj pretraguŠtampaj
INFO
Grupa proizvoda
Utovorne dizalice, vitla i liftovi za materijal
Brend/Model
XCMG XCT12L5
Godište proizvodnje
2022
Sati korišćenja
1248 h
Dodatne opcije
Restauriran,Eks izložbeni model
Zemalja
Kina
Opšta ocena
1
2
3
4
5
Mascus ID
BA9F24BF
CENA
Izaberi valutu:
DETALJI
Maksimalna visina podizanja
25 m
Maksimalni kapacitet dizanja
12000 kg
Proizvodnja/Serijski broj
XCT12L5
Bruto težina
16000 kg
Klasa emisije
Stage IIIA
Originalna boja
yellow
Transportne dimenzije (DxŠxV)
1090025003.55 m
Zemlja proizvodnje
Kina
Uslovi isporuke
FOB, CIF
Certifikati
EPA, CE, TÜV
Ostale informacije
Category
Item
Unit
XCT12L4
Dimension
Overall length
mm
10900
Overall width
mm
2500
Overall height
mm
3550
Weight
Total weight in travel
kg
16000
Travel
Max. travel speed
km/h
90
Min. turning diameter
m
18
Min. ground clearance
mm
250
Approach angle
°
21
Departure angle
°
13
Max. grade ability
%
41
Fuel consumption for 100km
L
25
Main performance
Max. rated total lifting capacity
t
12
Min. rated working radius
m
3
Turning radius at turntable tail
m
2.57
Max. lifting torque
kN.m
482.5
Base boom
m
9.5
Max.main boom
m
30.9
Max.main boom+jib
m
38.1
Turning radius at turntable tail
Counterweight
mm
2570
Auxiliary winch
mm
2910
Max. load moment
Base boom
t.m
48.25
Fully-extended boom
t.m
27.6
Outrigger span(fully-extended)
Longitudinal
m
4.57
Hoist height
Lateral
m
5.5
Base boom
m
9.5
Fully-extended boom
m
30.9
Boom length
Fully-extended boom + Jib
m
38.1
Base boom
m
9.45
Fully-extended boom
m
30.5
Fully-extended boom + Jib
m
30.5+7
