XCMG XCA 200
Cena bez PDV-a
Štampaj
INFO
Grupa proizvoda
Polovne dizalice za sve terene
Brend/Model
XCMG XCA 200
Godište proizvodnje
2021
Sati korišćenja
3000 h
Zemalja
Kina
Opšta ocena
1
2
3
4
5
Mascus ID
6CEAC4AF
CENA
Izaberi valutu:
DETALJI
Broj internog magacina
1
Poslednja inspekcija
2025-07-10
Proizvodnja/Serijski broj
1
Broj prethodnih vlasnika
1
Bruto težina
150000 kg
Maksimalni kapacitet dizanja
200000 ton
Registarki broj
1
Maksimalni kapacitet dizanja na kraju konzole
200000 ton
Min boom length
14 m
Klasa emisije
Stage V
trajanje
16 m
Min luffing jib
3 m
Konzolna dizalica
15 m
Dužina konzole dizalice
15 m
Maksimalna visina podizanja
84 m
Visina kuke dizalice - horizontalno
15 m
Visina kuke dizalice - prema vazduhu
14 m
Gornji motor
Benz
Gornji sati
857 h
Tip krana
Hidraulični strelac
Originalna boja
Original
Protivteg
14000
Nosač motora
Original
Engine manufacturer
Original
Transportne dimenzije (DxŠxV)
15350 x 3000 x 3950 mm
Tip nosaća
Točkast
Informacije o stanju/Garancija
Good Condition
Brend guma
米其林
Profili prednjih guma
98
Profil zadnjih guma
2
Zemlja proizvodnje
Kina
Uslovi isporuke
FCA, FOB, CIF, EXW
Certifikati
EPA, CE
Dodatna oprema
Fly Jib,Hook,Counter Weight,ETC.
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Dodatna oprema
Kuka za balvane
Ostale informacije
Basic parameters
The overall length of the machine is 15,350mm
Overall width of the machine: 3000mm
Overall height of the machine: 3950mm
Wheelbase: 2650/1650/2900/1650mm
Wheel base: 2590/2590/2590/2590/2590 mm
Axial load: 11650/11650/11650/10020/10020 kg
Maximum driving speed: ≥80km/h
Minimum stable driving speed: 1-1.5km/h
Minimum turning diameter: ≤18.5m
Minimum ground clearance: 307mm
Approach Angle: 18°
Departure Angle: 14°
Fuel consumption per 100 kilometers: 72 liters
Longitudinal span of outriggers: 9.19m
Maximum rotational speed: ≥1.5r/min
The turning radius at the tail of the turntable (at the counterweight point) : 5100mm
Full extension time of the boom: ≤720 seconds
Engine parameters
Chassis engine model: MC13.54-50/MC13.54-61
The rated power of the chassis engine is 338kW
The rated power of the engine on the vehicle is 221kW
Lifting capacity parameters
Maximum rated total lifting capacity: 200 tons
The maximum lifting moment of the basic boom is 6,657 kN·m
Longest main arm: 90 meters
Fixed auxiliary arm: 18.5m
The maximum length of the main boom and auxiliary boom is 118.5 meters
Job performance parameters
Working range: The maximum working range is 84 meters
Load-bearing extension and retraction: The main arm can extend and retract under load at any point within the working condition range. The comprehensive performance is no less than 40% of the rated load, and the maximum performance is 70% of the rated load. It has a wide construction range and the efficiency is increased by 30% to 50%
Variable support: Supports any combination of outrigger extension lengths, flexible operation, safe and stable
Full-action wireless remote control: Operated by a single person, it can achieve the disassembly and assembly of counterweights, foot pads, and auxiliary arms, reducing operational cost input
Other parameters
Hydraulic system: Utilizing advanced hydraulic technology, the system features high working pressure and large flow rate, ensuring that all movements of the crane are completed smoothly, quickly and accurately.
Electrical system: Equipped with an intelligent electrical control system, it features functions such as fault diagnosis and automatic protection, enhancing the reliability and safety of the crane.
Safety devices: A variety of safety devices are installed, such as overload protection devices, moment limiters, height limiters, amplitude limiters, anti-overturning devices, etc., to ensure the safety of the crane during operation
